AIM-78H

Medical Grade Tablet | 10.1" FHD 380 nits | IP65

Display: 10.1" FHD 380 nits
Weight: 0.98 kg
Dimensions (W, D, H): 280 x 18.3 x 180.1 mm
Resistance: MIL-STD-810G, 1.2 m drop, IP65
Operating Temperature: from 0°C to 40°C
RAM: 4 GB (optional 8 GB)
Memory: eMMC (64 GB) Micro SD (up to 2 TB)
System: Android
Guarantee: 24 months

Produs epuizat

Livrare gratuita de la 500 RON

Promocja cenowa na model HDR-15-5

Produs destinat exclusiv utilizării profesionale

Descriere
Basic parameters
Specificație tehnică
Descarca documentatie
Produse recomandate

AIM-78H

Descriere

AIM-78H – 10.1″ Industrial / Medical Grade Tablet for Critical Healthcare Environments

The AIM-78H is a compact, high-performance medical-grade tablet designed to meet the evolving needs of modern healthcare. Whether used in operating rooms, mobile carts, labs, or point-of-care stations, this device delivers reliable performance, secure data handling, and seamless integration — all within a durable, hygienic design.

Performance That Supports Critical Workflows

Powered by a Qualcomm SDA660 processor and up to 8 GB of RAM, the AIM-78H ensures responsive operation for HIS applications, telemedicine platforms, and real-time inventory tracking. Its fast 64 GB eMMC storage (expandable via microSD up to 2 TB) minimizes loading times for large imaging files and patient records.

Display Built for Medical Precision

The 10.1" Full HD touchscreen (1920 × 1200) with 380 nits brightness remains clear under surgical lights or mobile cart use. Protected by Corning Gorilla Glass 3, the screen resists scratches and disinfectants — essential in sterile environments.

Ultra-Portable for Mobile Teams

Weighing just 980 grams and measuring only 280 × 18.3 × 180.1 mm, the AIM-78H is easy to carry across departments or mount to diagnostic carts, allowing care providers to stay flexible and efficient on the move.

Stable, Medical-Grade Connectivity

Dual-band Wi-Fi, Bluetooth, and integrated NFC deliver uninterrupted access to hospital networks and peripherals. Optional LTE Cat 6 ensures secure communications even outside facility coverage zones.

Built for Clinical Demands

Certified to IEC/UL/EN 60601-1 medical standards
Easy-to-disinfect housing with resistance to harsh cleaning protocols
Operates safely between 0 °C and +40 °C — ideal for surgical suites, labs, and pharmacies

Modular Expansion for Versatile Applications

Via the 14-pin pogo connector, users can attach a range of medical accessories including:
1D/2D barcode scanners, LAN + COM modules, UHF RFID readers, or NFC/FIDO2 security modules — without needing to replace the full device fleet.

Enterprise-Grade Data Protection

TPM 2.0 for hardware-level encryption
Optional facial recognition (IR camera) or password login
DeviceOn/iService platform enables remote lockdown and data wiping (MDM support)

Reliable Service & Long-Term Compatibility

A standard 24-month warranty (extendable) and cross-series accessory compatibility ensure sustainable deployments across hospitals and care networks.

Basic parameters

Processor	Qualcomm platform optimized for medical applications	Water & Dust Resistance	Certified housing, easy to disinfect in clinical environments
Display	10.1″ FHD touchscreen with reinforced glass, glove and disinfectant-friendly	Connectivity	Dual-band Wi-Fi, Bluetooth, NFC optional LTE Cat 6 module
Battery	Lightweight integrated battery for full-shift operation	Certifications	IEC/UL/EN 60601-1 (medical-grade)
Storage	Expandable storage suitable for large medical datasets	Accessories	Docking, medical cart mounts, modular expansion via pogo connector
Drop resistance	Designed to withstand clinical drops and handling	Customization	Barcode scanner, RFID, smart card, NFC/FIDO2, remote device management

Specificație tehnică

Core Specifications

Operating System	Android 13 (non-GMS) / Android 10 (non-GMS)
Built-in Barcode Scanner	Optional 1D / 2D imager (factory-configured)
Processor & Memory	Qualcomm® SDA/SDM 660, octa-core, up to 2.2 GHz 4 GB LPDDR4 RAM — upgradeable to 8 GB eMMC 64 GB + microSD (up to 2 TB)
Display	10.1″ FHD LCD (1920 × 1200) \| 380 cd/m² Corning® Gorilla® Glass 3, 10-point P-CAP touch
Wireless / NFC	Wi-Fi 5 (802.11 a/b/g/n/ac/k/v/r) & Bluetooth® 5.0 + BLE NFC 13.56 MHz — ISO 15693 / 14443 A/B / Felica
Standard I/O Ports	1 × USB-C 3.1 (data) • 1 × USB-A 2.0 Combo audio jack • DC-in 19 V 1 × SIM tray • 1 × microSD slot
Extended I/O	AIM 14-pin pogo connector: USB 2.0, 2-wire UART, 5 V / 1 A
Buttons	Power • Volume ± • Programmable key
Cameras	Front: 8 MP fixed-focus Rear: 13 MP auto-focus with LED flash
Sensors	Ambient-light • E-compass • G-sensor • Gyroscope
Environmental	Operating: 0 – 40 °C (32 – 104 °F) Storage: –20 – 60 °C (–4 – 140 °F) Sealing: IP65 • MIL-STD-810G (shock / vibration / 1.22 m drop)
Dimensions & Weight	280 × 18.3 × 180.1 mm (11 × 0.7 × 7.1 in) 980 g (2.2 lb)
Audio	2 × internal speakers (2 W each)
Power & Battery	Smart hot-swappable battery — 10.8 V / 2400 mAh (26 Wh), LED capacity indicator DC-in 19 V / 3.43 A • Dock pogo 12 V / 2 A
Certifications	IEC / UL / EN 60601-1 • FCC/IC • CE • NCC/BSMI • TELEC/VCCI • RCM • CCC/SRRC
