ICR-2437

ICR-2437 - Economical series of programmable LTE 450 routers with RS-232 and RS-485 ports

Producător: Advantech
Producător: Advantech
  • Support for LTE 450 technology
  • Support for 4G LTE/3G/2G
  • 2 SIM card slots
  • 2 10/100 Mb / s Ethernet port
  • 1x RS-232
  • 1x RS-485
  • 1x in. digital, 1x out. digital
  • Linux based open system
  • Possibility to create user modules based on Python, C ++, C, BASH languages
  • Dedicated user modules that enable the conversion of protocols into and expansion of functionality (full list of modules in the specification tab)
  • Device compatible with the Edge Computing idea
  • Possibility to work as a Gateway - Modbus TCP / RTU
  • Possibility to install an external antenna
  • Working in the temperature range from -40 to 75 ° C
  • VPN tunnel support (IPsec, OpenVPN, L2TP)
  • 32-bit ARM processor supported by 128 MB DDR SDRAM and 64 MB flash memory (12 MB for additional applications and 2 MB for user data)
  • Supports DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, SMS control and many other functions
  • Robust metal housing in accordance with IP30
  • Power supply in the range of 9-48VDC
  • Wall mounting or optional on a DIN rail
  • The set does not include the power supply and antenna
Preț de la 2.287,00 RON Net

Preț prea mare? Autentificați-vă și cumpărați mai ieftin

Produs epuizat

Livrare gratuita de la 500 RON

Vezi 1 model

Promocja cenowa na model HDR-15-5

Modele

Accesorii

Descriere

The ICR-2437 industrial router has been designed as a simple device for communication using LTE 450 technology. It is a frequency widely used in Europe for critical communication in the energy sector.

ICR-2437 supports both 4G LTE/3G/2G and LTE450 technology.

The router is equipped with 2 independently configurable Ethernet ports (LAN or WAN), one RS-232 port, one RS-485 port and 1 digital input and 1 digital output. Data tunneling via VPN may be responsible for the security of data transfer. In case of problems, the option of extensive diagnostics turns out to be helpful, including automatic monitoring of wireless / wired connections, automatic restarts when connection is lost and a hardware watchdog that watches over the device's operating status.

The open Linux platform means that the user does not rely only on the software prepared by the manufacturer, but can also build applications based on Pythonc, C or C ++. In addition, the routers of this series support the installation of already written extensions that enrich the device with support for additional protocols and better interface management.

Specificație tehnică

  • Wi-FiNie
    Port RS-232Tak
    Port RS-485Tak
    Rodzaj obudowyMetalowa
    AkcesoriaBrak
